P2.5 LED Wall Price in Bengaluru: ₹5,500 to ₹8,000 per Sq Ft, Installed

A P2.5 LED wall costs ₹5,500 to ₹8,000 per sq ft installed in Bengaluru, before GST, from PixelSpot's own factory at Jalahalli East. P2.5 is PixelSpot's most popular pixel pitch and the one most of our Bengaluru walls are built with, because it sits exactly where most rooms need it: fine enough that nobody standing 2.5 metres away sees individual LEDs, coarse enough that a 10x6 ft wall stays between ₹3.3 and ₹4.8 lakh. Showrooms, restaurants, temples, churches, wedding halls, office lobbies and event stages across Bengaluru run on P2.5, and an outdoor P2.5 variant exists for shopfront menus read from 3 to 5 metres, which is what we installed at Acai Theory in Indiranagar. This page gives the P2.5 price at three sizes, the full module specification, the rooms it suits, how it compares with P2.0 and P3, and what a PixelSpot P2.5 wall includes.

P2.5 LED wall price by size, before GST

Every figure is the installed price before GST. GST is 18 per cent extra and is claimable as input credit by a registered business; the HSN code and GST page explains how. The rate covers the P2.5 LED modules, receiving cards, the sending controller, power supplies, the steel frame, all cabling, installation by PixelSpot's own crew, the PixelOS cloud CMS, 5 per cent spare modules and the 2-year pixel-to-pixel onsite warranty. There is no separate installation invoice and no separate software subscription needed to put content on the wall.

What keeps a P2.5 quote at ₹5,500 per sq ft: a flat wall-mounted install on a plain steel frame, rear-serviced modules, a Huidu controller, and standard indoor brightness. That is the configuration most showrooms and restaurants in Bengaluru actually buy.

What pushes a P2.5 quote towards ₹8,000 per sq ft: front-service die-cast aluminium cabinets (needed when the wall is flush against a partition and there is no rear access), a NovaStar-based sending and receiving system, a curved or ceiling-hung frame, and semi-outdoor brightness for a wall that faces a glass frontage or an atrium skylight. Each of these is a line on the quotation, so you can see exactly which one moved the price.

P2.5 LED wall specification

Two of these numbers deserve a second look when you compare quotes. The module resolution of 128 x 64 pixels is the fingerprint of a true 2.5 mm pitch on a 320 x 160 mm board; if a quote lists a different count on the same board size, it is not P2.5. The refresh rate of 3,840 Hz is what keeps a filmed P2.5 wall clean on Instagram reels and wedding videography. Cheaper 1,920 Hz panels exist and cost less, but they flicker on phone cameras, which matters for any showroom launch, temple festival or wedding stage that will be filmed.

Is P2.5 right for your space

The rule is simple: the minimum comfortable viewing distance in metres is roughly the pitch number, and the picture looks its best from about twice that. For P2.5 that means comfortable from 2.5 m, ideal from about 5 m. Measure from the wall to where the nearest regular viewer stands, not to the far end of the room. If that first viewer is at 2.5 m or further, P2.5 is the right pitch and paying for a finer one buys pixels nobody can resolve. The viewing distance calculator does the arithmetic for any room.

Where P2.5 fits in Bengaluru

• Car and two-wheeler showrooms (showroom LED walls): a 12x8 ft wall behind the display vehicles is read from the showroom floor at 5 m and beyond. 1,463 x 975 pixels carries launch films and variant pricing cleanly.
• Restaurants, cafes and pubs (restaurant LED walls): a 10x6 ft wall above the bar or on the feature wall, seen from tables 2.5 m and further. Menus, match streams and ambience loops at 1,219 x 731 pixels.
• Temples and churches (temple LED walls, church LED walls): the first row of devotees sits at least 2.5 m from the wall and the hall extends past 5 m. P2.5 is comfortable for the front row and sharp for everyone behind, at a price a trust or parish can approve.
• Wedding halls and convention centres (wedding hall LED walls): a 12x8 ft stage backdrop with guests seated from 2.5 m outwards. 3,840 Hz keeps the backdrop clean in every photograph and reel.
• Office and hotel lobbies (lobby LED walls, hotel LED walls): visitors pass the reception wall at 2.5 to 5 m. A 10x6 ft P2.5 shows brand films, welcome boards and dashboards designed at lobby scale.
• Corporate cafeterias and town-hall spaces: the nearest seat sets the pitch. In the Bengaluru corporate office case study the pitch was chosen from exactly that measurement.
• Event and exhibition stages (event LED walls): audiences from 5 m out, and cameras everywhere. For a one-off event, LED wall rental starts from ₹15,000 a day.

When to step finer, and when to step coarser

Go finer when the nearest regular viewer is inside 2.5 m, or when the wall will show spreadsheets, small captions or a live dashboard read up close. A jewellery counter, a boardroom or a mall entrance where shoppers walk right up to the glass belongs on P2.0 (comfortable from 2 m) or P1.8 (comfortable from 1.8 m, ideal from 3.5 m). Studios and control rooms where people sit within 1.5 m go to P1.5 or P1.2.

Go coarser only outdoors. PixelSpot does not sell an indoor P3 or an indoor P4: an indoor P3 request comes back as a P2.5 quote at ₹5,500 per sq ft with 44 per cent more pixels, and the so-called "indoor P4" seen elsewhere is outdoor-grade P4 run indoors, too bright for the room and coarse from 3 m. For a shopfront read from the pavement at 4 m or more, outdoor P4 is the standard; for a larger sign read from 3 m, outdoor P3. For a shopfront menu read from 3 to 5 m, the outdoor P2.5 variant described below.

P2.5 vs P2.0 vs P3: the neighbouring pitches

The table explains why P2.5 is the best-seller. Stepping up to P2.0 takes a 10x6 ft wall from ₹3.3 to ₹4.8 lakh up to ₹4.8 to ₹7.2 lakh for 1,524 x 914 pixels instead of 1,219 x 731, a difference only visible to someone standing inside 2.5 m. Stepping "down" to P3 does not save money at all, because the only P3 PixelSpot builds is the outdoor IP65 module at 5,000 nits, which costs more than indoor P2.5 and is far too bright for a room. Between P2.5 and P1.8 the gap is narrower: P1.8 is ₹7,000 to ₹12,000 per sq ft and a 10x6 ft wall costs ₹4.2 to ₹7.2 lakh, so on that size P1.8 starts higher and its upper figure sits well above the P2.5 ceiling. The P2.5 vs P3 article goes deeper on the coarser choice and the full pixel pitch price table covers every pitch from P1.2 to P10.

Outdoor P2.5 for shopfront menus

Most shopfronts are read from the pavement and belong on outdoor P4. A menu board is different: customers stand at the counter or queue 3 to 5 m from the screen and need to read prices and item names, which is closer than a P4 module looks good from. For that case PixelSpot builds an outdoor P2.5 with an IP65-rated front, IP54 rear and auto-dimming that drops the brightness after sunset so the menu does not glare at night. Acai Theory in Indiranagar is the reference install: a P2.5 menu wall facing the street, readable from the ordering point in afternoon sun. Outdoor P2.5 is quoted after the free site visit because the structure, weatherproofing and sun exposure differ from one frontage to the next; the indoor rates on this page do not apply to it. See the LED screen for shops page for the wider shopfront range.

What a P2.5 wall from PixelSpot includes

• Modules made in Bengaluru. P2.5 modules are assembled at our Jalahalli East factory, which has built PixelSpot walls since 2022. Spares for this pitch are always on the shelf, and a module swap starts from ₹1,800.
• Steel frame and cabling. A powder-coated frame fabricated to your opening, mounted to the wall or hung from the ceiling, with all power and data cabling to a single point of connection.
• Controller: Huidu or NovaStar. The ₹5,500 configuration uses a Huidu sending controller, which handles video, menus and PixelOS playlists without fuss. The NovaStar-based system in the upper configuration adds finer calibration and is what we specify for walls that are filmed professionally or run broadcast feeds.
• PixelOS cloud CMS. Schedule content, change a menu price or push a festival loop from your phone; PixelOS Connect and the wider PixelOS suite are included, not a monthly add-on. A PixelPlayer is available at ₹35,000 where a standalone media player is preferred.
• 5 per cent spare modules left on site so a damaged module is replaced the same day without waiting for a courier.
• Installation by our own crew, not a subcontractor, with a free site visit and 3D mockup of the wall in your space before you sign.
• 2-year pixel-to-pixel onsite warranty (details on the warranty page) with 24-hour service response inside Bengaluru, and an AMC from ₹150 per sq ft per year after that.
• Karnataka-wide installs. The same per sq ft rate applies in Mysuru, Mangaluru, Hubballi and every other Karnataka district, plus Hosur and Krishnagiri, with freight and crew travel shown as separate lines. See LED walls across Karnataka.

PixelSpot has completed more than 500 installations and holds a 5.0 Google rating from 15 reviews. The installation page shows what happens on the day, and the power consumption guide tells you what a P2.5 wall draws so your electrician can plan the supply.

How to get your exact P2.5 price

1. Measure the wall opening in feet and the distance to the nearest regular viewer in metres. If that distance is 2.5 m or more, P2.5 is your pitch.
2. Open the 60-second LED wall configurator for an instant P2.5 estimate with GST, a spec sheet and a bill of materials, or WhatsApp +91 72048 08334 with the size, indoor or outdoor, and a photo of the wall.
3. Book the free site visit. We confirm the pitch and viewing distance on site, check power and access, and send a 3D mockup with a fixed quotation.
